Thread: Metric, G (PF), and NPT thread.
Materials: Brass with nickel plated and silicon rubber.
Working temperature: -40℃ to 200℃.
Ex-marking: Ex eb ⅡC Gb；Ex tb ⅢC Db.
Applications: Widely used in hazardous area，connecting to explosion-proof electric equipment, especially in the installation of automation engineering circuit.
编号
Item.No.
|
电缆范围
Cable Range
(mm)
|
螺牙规格
Thread
|
螺纹外径
Thread O.D.
AG(mm)
|
螺纹长度
Thread Length
GL(mm)
|
包装
Std.Pkg
(pcs)
|
|
EX-BCG-M20-14
|
9-14
|
M20 x 1.5
|
20
|
9.5
|
10
|
|
EX-BCG-M25-18
|
13-18
|
M25 x 1.5
|
25
|
12
|
10
|
|
EX-BCG-M32-25
|
18-25
|
M32 x 1.5
|
32
|
12.5
|
10
|
|
EX-BCG-M40-31
|
24-31
|
M40 x 1.5
|
40
|
15
|
10
|
|
