Materials: UL approved Nylon PA66(Flammability UL 94V-2) and Weather-resistant EPDM rubber. (Accept to make super rubber: resist high temperature rubber, resist strong acid/alkali, etc).
Working temperature: -40℃ to 100℃
Features: The Powerful Galvanized Pipe Fittings build the best tightening power by a very high and active compression force，Strong resistance to pull, perfect connecting of PVC Coated Flexible Conduit and Galvanized Pipe. The product can widely applied to resist water as a tough cable protection system for any machines, electric power equipment, engineering installation with the very specific demands.
产品编号
Item No.
|
适配镀锌管(mm)
Adapt to galvanized pipe(mm)
|
适配镀锌管(英寸)
Adapt to galvanized pipe(Inch)
|
适用金属管(Ф)
Adapt to PVC Coated Flexible Conduit
|
适用金属管(英寸)
Adapt to PVC Coated Flexible Conduit(Inch)
|
|
DN12/AD18.5-Ф10
|
21.3mm
|
1/2
|
Ф10
|
1/4"
|
|
DN15/AD21.2-Ф13
|
21.3mm
|
1/2
|
Ф13
|
3/8"
|
|
DN20/AD28.5-Ф16
|
26.8mm（26.9mm）
|
3/4
|
Ф16
|
1/2"
|
|
DN25/AD34.5-Ф20
|
33.5mm（33.7mm）
|
1
|
Ф20
|
3/4"
|
|
DN32/AD42.5-Ф25
|
33.5mm（33.7mm）
|
1
|
Ф25
|
1"
|
|
DN40/AD48.0-Ф32
|
42.25mm（42.4mm）
|
1-1/4
|
Ф32
|
1-1/4"
|
|
DN50/AD60.0-Ф38
|
48mm
|
1-1/2
|
Ф38
|
1-1/2"
|
|
DN50/AD60.0-Ф51
|
60mm
|
2
|
Ф51
|
2"
|
|
