Thread: Metric, PG, G (PF), and NPT thread.
Materials: Brass with nickel plated and UL approved Nylon PA66 (Flammability UL 94V-2).
Working temperature: -40℃ to 100℃.
Features: The claws of excellent design, to provide a fast & safe connection with the tubing and to get an excellent result of the pullout strength to be the best balanced performers for cable protection system.
Color: Black(RAL9005)、grey(RAL7035),other color available upon request.
适配软管
Accommodated Pipes
|
编号
Item.No.
|
螺牙规格
Thread
|
螺纹外径
Thread O.D.
AG(mm)
|
螺纹长度
Thread Length
GL(mm)
|
包装
Std.Pkg
(pcs)
|
|
AD18.5
|
BQTF-M20-AD18.5
|
M20 x 1.5
|
20
|
10.5
|
20
|
|
AD21.2
|
BQTF-M20-AD21.2
|
M20 x 1.5
|
20
|
10.5
|
20
|
|
AD28.5
|
BQTF-M25-AD28.5
|
M25 x 1.5
|
25
|
13
|
20
|
|
AD34.5
|
BQTF-M32-AD34.5
|
M32 x 1.5
|
32
|
15
|
20
|
|
