· 螺牙规格：公制牙(Metric)、PG牙、G (PF / BSP / PS)牙、NPT牙。
· 产品材质：螺母，基本幅体，牙圈和螺帽以优质304不锈钢制成；垫片和夹紧圈材质为三元乙丙耐候橡胶。
· 保护等级：IP66
· 工作温度：-40℃至100℃
· 应用：连接金属软管，起到防水保护线缆的作用
编号
Item No.
|
适配金属软管(mm)
Adapt to metal hose(mm)
|
适配金属软管(英寸)
Adapt to metal hose(Inch)
|
螺纹规格
Thread
|
|
DPSS-Ф10-M16
|
Ф10
|
1/4
|
M16×1.5
|
|
DPSS-Ф13-M16
|
Ф13
|
3/8
|
M16×1.5
|
|
DPSS-Ф13-M20
|
Ф13
|
3/8
|
M20×1.5
|
|
DPSS-Ф16-M18
|
Ф16
|
1/2
|
M18×1.5
|
|
DPSS-Ф16-M20
|
Ф16
|
1/2
|
M20×1.5
|
|
DPSS-Ф16-M24
|
Ф16
|
1/2
|
M24×1.5
|
|
DPSS-Ф20-M20
|
Ф20
|
3/4
|
M20×1.5
|
|
DPSS-Ф20-M25
|
Ф20
|
3/4
|
M25×1.5
|
|
DPSS-Ф20-M27
|
Ф20
|
3/4
|
M27×2.0
|
|
DPSS-Ф20-M30
|
Ф20
|
3/4
|
M30×2.0
|
|
DPSS-Ф25-M25
|
Ф25
|
1
|
M25×1.5
|
|
DPSS-Ф25-M32
|
Ф25
|
1
|
M32×1.5
|
|
DPSS-Ф25-M33
|
Ф25
|
1
|
M33×2.0
|
|
DPSS-Ф25-M36
|
Ф25
|
1
|
M36×2.0
|
|
DPSS-Ф32-M40
|
Ф32
|
1-1/4
|
M40×1.5
|
|
DPSS-Ф32-M42
|
Ф32
|
1-1/4
|
M42×2.0
|
|
DPSS-Ф32-M48
|
Ф32
|
1-1/4
|
M48×2.0
|
|
DPSS-Ф38-M40
|
Ф38
|
1-1/2
|
M40×1.5
|
|
DPSS-Ф38-M48
|
Ф38
|
1-1/2
|
M48×2.0
|
|
DPSS-Ф38-M50
|
Ф38
|
1-1/2
|
M50×1.5
|
|
DPSS-Ф51-M50
|
Ф51
|
2
|
M50×1.5
|
|
DPSS-Ф51-M60
|
Ф51
|
2
|
M60×2.0
|
|
DPSS-Ф51-M63
|
Ф51
|
2
|
M63×1.5
|
|
|
|
|
|
|
DPSS-Ф10-PG9
|
Ф10
|
1/4
|
PG9
|
|
DPSS-Ф13-PG11
|
Ф13
|
3/8
|
PG11
|
|
DPSS-Ф13-PG13.5
|
Ф13
|
3/8
|
PG13.5
|
|
DPSS-Ф16-PG13.5
|
Ф16
|
1/2
|
PG13.5
|
|
DPSS-Ф16-PG16
|
Ф16
|
1/2
|
PG16
|
|
DPSS-Ф20-PG21
|
Ф20
|
3/4
|
PG21
|
|
DPSS-Ф25-PG29
|
Ф25
|
1
|
PG29
|
|
DPSS-Ф32-PG29
|
Ф32
|
1-1/4
|
PG29
|
|
DPSS-Ф38-PG36
|
Ф38
|
1-1/2
|
PG36
|
|
DPSS-Ф38-PG42
|
Ф38
|
1-1/2
|
PG42
|
|
DPSS-Ф51-PG48
|
Ф51
|
2
|
PG48
|
|
|
|
|
|
|
DPSS-Ф10-G1/4
|
Ф10
|
1/4
|
G1/4
|
|
DPSS-Ф13-G3/8
|
Ф13
|
3/8
|
G3/8
|
|
DPSS-Ф16-G1/2
|
Ф16
|
1/2
|
G1/2
|
|
DPSS-Ф20-G3/4
|
Ф20
|
3/4
|
G3/4
|
|
DPSS-Ф25-G1
|
Ф25
|
1
|
G1
|
|
DPSS-Ф32-G1-1/4
|
Ф32
|
1-1/4
|
G1-1/4
|
|
DPSS-Ф38-G1-1/2
|
Ф38
|
1-1/2
|
G1-1/2
|
|
DPSS-Ф51-G2
|
Ф51
|
2
|
G2
|
|
|
|
|
|
|
DPSS-Ф10-NPT1/4
|
Ф10
|
1/4
|
NPT1/4
|
|
DPSS-Ф13-NPT3/8
|
Ф13
|
3/8
|
NPT3/8
|
|
DPSS-Ф16-NPT1/2
|
Ф16
|
1/2
|
NPT1/2
|
|
DPSS-Ф20-NPT3/4
|
Ф20
|
3/4
|
NPT3/4
|
|
DPSS-Ф25-NPT1
|
Ф25
|
1
|
NPT1
|
|
DPSS-Ф32-NPT1-1/4
|
Ф32
|
1-1/4
|
NPT1-1/4
|
|
DPSS-Ф38-G1-1/2
|
Ф38
|
1-1/2
|
NPT1-1/2
|
|
DPSS-Ф51-NPT2
|
Ф51
|
2
|
NPT2
|
|
