· Thread: Metric
· Material: UL approved Halogen-free Nylon PA66(Flamability UL 94V-2), (Accept to make flammability UL 94V-0 ); EPDM rubber(Also accept to make super rubber: resist high temperature rubber, resist strong acid/alkali,etc).
· Protection degree: IP68
· Working temperature: -40℃-100℃ in static state, or instantaneous heat resistant up to 120℃; -20℃-80℃ in dynamic state, or instantaneous heat resistant up to 100℃
· Features: The claws and seals of excellent design, sealing nut have a “click”sound and re-open, can hold cable firmly and have a wider cable range. Resistant to salt water, weak acid, alcohol, oil, grease and common solvency.
· Colours: Black(RAl9005), gray(RAL7035), other color available upon request
Item.No.
|
Cable Range
Ф(mm)A
|
thread inside diameter
C1(MM)
|
Thread Length
C2(mm)
|
Spanner Size
A&B(mm)
|
Std.Pkg
(pcs)
|
NNCG-M20-H1-5
|
3-5
|
20x1.5
|
15
|
22/23
|
50
|
NNCG-M20-H1-7
|
4-7
|
20x1.5
|
15
|
22/23
|
50
|
NNCG-M20-H1-10
|
6-10
|
20x1.5
|
15
|
22/23
|
50
|
NNCG-M20-H2-4
|
2.5-4
|
20x1.5
|
15
|
22/23
|
50
|
NNCG-M20-H3-3
|
2-3
|
20x1.5
|
15
|
22/23
|
50
|
NNCG-M20-H3-4
|
2.5-4
|
20x1.5
|
15
|
22/23
|
50
|
NNCG-M20-H4-3.2
|
2-3.2
|
20x1.5
|
15
|
22/23
|
50
|
NNCG-M20-H5-2.5
|
1.8-2.5
|
20x1.5
|
15
|
22/23
|
50
|
NNCG-M20-H6-2.5
|
1.8-2.5
|
20x1.5
|
15
|
22/23
|
50
|
NNCG-M25-H1-6.2
|
4-6
|
25x1.5
|
15
|
27/27
|
50
|
NNCG-M25-H1-11
|
8-11
|
25x1.5
|
15
|
27/27
|
50
|
NNCG-M25-H1-14
|
10-14
|
25x1.5
|
15
|
27/27
|
50
|
NNCG-M25-H2-6
|
4-6
|
25x1.5
|
15
|
27/27
|
50
|
NNCG-M25-H2-3
|
2-3
|
25x1.5
|
15
|
27/27
|
50
|
NNCG-M25-H3-5
|
3-5
|
25x1.5
|
15
|
27/27
|
50
|
NNCG-M25-H4-2.5
|
1.2-2.5
|
25x1.5
|
15
|
27/27
|
50
|
NNCG-M25-H4-3.5
|
2-3.5
|
25x1.5
|
15
|
27/27
|
50
|
NNCG-M25-H4-5
|
3.5-5
|
25x1.5
|
15
|
27/27
|
50
|
NNCG-M25-H5-3
|
2-3
|
25x1.5
|
15
|
27/27
|
50
|
|
