Product Name Brass Quick Connector for Flexible Pipes
Thread: Metric, PG, G(PF), and NPT thread
Brass with nickel plated for A. C parts, UL approved Nylon PA66 (Flammability UL 94V-2) for F part.(Can make as customer's requirement)
Working temperature: -40℃ to 100℃
Features: The claws of excellent design, to provide a fast & safe connection with the tubing and to get an excellent result of the pullout strength to be the best balanced performers for cable protection system.

适配软管

编号

螺牙规格

螺纹外径

螺纹长度

包装

AD10.0

QBCTF-M10 -10.0

M10 x 1.5

10

10

20

QBCTF-M12 -10.0

M12 x 1.5

12

10

20

AD13.0

QBCTF-M12 -13.0

M12 x 1.5

12

10

20

QBCTF-M16 -13.0

M16 x 1.5

16

10

20

QBCTF-M18 -13.0

M18 x 1.5

18

10

20

QBCTF-M20 -13.0

M20 x 1.5

20

10

20

AD15.8

QBCTF-M16 -15.8

M16 x 1.5

16

12.5

20

QBCTF-M18 -15.8

M18 x 1.5

18

12.5

20

QBCTF-M20 -15.8

M20 x 1.5

20

12.5

20

AD18.5

QBCTF-M18-18.5

M18 x 1.5

18

12.5

20

QBCTF-M20 -18.5

M20 x 1.5

20

12.5

20

QBCTF-M22 -18.5

M22 x 1.5

22

12.5

20

AD21.2

QBCTF-M20 -21.2

M20 x 1.5

20

13

10

QBCTF-M22 -21.2

M22 x 1.5

22

13

10

QBCTF-M24 -21.2

M24 x 1.5

24

13

10

QBCTF-M25 -21.2

M25 x 1.5

25

13

10

AD25.0

QBCTF-M25 -25.0

M25 x 1.5

25

13

10

AD28.5

QBCTF-M25 -28.5

M25 x 1.5

25

13

10

QBCTF-M27 -28.5

M27 x 1.5

27

13

10

QBCTF-M30 -28.5

M30 x 1.5

30

13

10

QBCTF-M30 -28.5-2

M30 x 2

30

13

10

QBCTF-M32 -28.5

M32 x 1.5

32

13

10

AD34.5

QBCTF-M32 -34.5

M32 x 1.5

32

14

5

QBCTF-M36 -34.5

M36 x 1.5

36

14

5

QBCTF-M36 -34.5-2

M36 x 2

36

14

5

QBCTF-M40 -34.5

M40 x 1.5

40

14

5

AD42.5

QBCTF-M40 -42.5

M40 x 1.5

40

15

5

QBCTF-M42 -42.5

M42 x 1.5

42

15

5

QBCTF-M48 -42.5

M48 x 1.5

48

15

5

QBCTF-M48 -42.5-2

M48 x 2

48

15

5

QBCTF-M50 -42.5

M50 x 1.5

50

15

5

AD54.5

QBCTF-M50 -54.5

M50 x 1.5

50

16

1

QBCTF-M60 -54.5

M60 x 1.5

60

16

1

QBCTF-M63 -54.5

M63 x 1.5

60

16

1

AD10.0

QBCTF-PG7 -10.0

PG7

12.4

8.5

20

AD13.0

QBCTF-PG9 -13.0

PG9

15.2

10

20

AD15.8

QBCTF-PG11 -15.8

PG11

18.4

12.5

20

AD18.5

QBCTF-PG13.5 -18.5

PG13.5

20.4

12.5

20

AD21.2

QBCTF-PG16 -21.2

PG16

22.5

13

10

AD25

QBCTF-PG21 -25

PG21

28.3

13

10

AD28.5

QBCTF-PG21 -28.5

PG21

28.3

13

10

AD34.5

QBCTF-PG29 -34.5

PG29

37

14

5

AD42.5

QBCTF-PG36 -42.5

PG36

47

15

5

AD54.5

QBCTF-PG42 -54.5

PG42

54

16

1

QBCTF-PG48 -54.5

PG48

59.3

16

1

AD10.0

QBCTF-G1/4 -10.0

G(PF) 1/4

13.1

8.5

20

AD13.0

QBCTF-G3/8 -13.0

G(PF) 3/8

16.6

10

20

AD15.8

QBCTF-G3/8 -15.8

G(PF) 3/8

16.6

12.5

20

QBCTF-G1/2 -15.8

G(PF) 1/2

20.9

12.5

20

AD18.5

QBCTF-G1/2 -18.5

G(PF) 1/2

20.9

12.5

20

AD21.2

QBCTF-G1/2 -21.2

G(PF) 1/2

20.9

13

10

QBCTF-G3/4 -21.2

G(PF) 3/4

26.4

13

10

AD25.0

QBCTF-G3/4 -25

G(PF) 3/4

26.4

13

10

AD28.5

QBCTF-G3/4 -28.5

G(PF) 3/4

26.4

13

10

AD34.5

QBCTF-G1 -34.5

G(PF) 1

33.2

14

5

AD42.5

QBCTF-G1 1/4 -42.5

G(PF) 1 1/4

41.9

15

5

AD54.5

QBCTF-G1 1/2 -54.5

G(PF) 1 1/2

48

16

1

QBCTF-G2 -54.5

G(PF) 2

60

16

1

AD21.2

QBCTF-PF1/2-21.2

G(PF)1/2

20.9

15

10

QBCTF-PF3/4-21.2

G(PF)3/4

26.4

15

10

AD28.5

QBCTF-PF3/4-28.5

G(PF)3/4

26.4

15

10

AD34.5

QBCTF-PF1-34.5

G(PF)1

33.2

15

5

AD42.5

QBCTF-PF1 1/4-42.5

G(PF)1 1/4

41.9

15

5

AD54.5

QBCTF-PF1 1/2-54.5

G(PF)1 1/2

48

15

1

QBCTF-PF2-54.5

G(PF)2

60

15

1

AD60

QBCTF-PF1 1/2-60

G(PF)1 1/2

48

15

1

QBCTF-PF2-60

G(PF)2

60

15

1
