· Thread: Metric
· Material: UL approved Halogen-free Nylon PA66(Flamability UL 94V-2), (Accept to make flammability UL 94V-0 ); EPDM rubber(Also accept to make super rubber: resist high temperature rubber, resist strong acid/alkali,etc).
· Protection degree: IP68
· Working temperature: -40℃-100℃ in static state, or instantaneous heat resistant up to 120℃; -20℃-80℃ in dynamic state, or instantaneous heat resistant up to 100℃
· Features: The powerful watertight conduit fittings build the perfect tightening power to resist ingress of high pressure water jet, which can connect the curragated conduit tightly and waterproof
· Colours: Black(RAl9005), gray(RAL7035), other color available upon request
Item.No.
|
Accommodated Pipes
|
ThreadIinside Diameter C1
|
Thread Length
C2(mm)
|
Spanner Size
B(mm)
|
NWTF-M20-AD13
|
AD13
|
20x1.5
|
15
|
23
|
NWTF-M25-AD15.8
|
AD15.8
|
25x1.5
|
15
|
27
|
NWTF-M25-AD18.5
|
AD18.5
|
25x1.5
|
15
|
27
|
|
