材質：UL合格之NYLON66，防火等級94V-2。
用途：此产品可将外螺纹转换成内螺纹;或者实现不同外螺纹产品的规格对接使用。 可根据客户要求定制，生产不同螺纹长度及其他不同螺纹之间的转换
*自主设计开发独有*
Material:UL certificated NYLON66，flammability V-2
Use:This product can be used to convert external threads into internal threads; or to achieve the connection of specifications of different externally threaded products. Can be customized according to customer requirements, producing different thread lengths and conversion between other different threads
|
型號
|
螺紋規格
|
螺紋長度Q
|
W 寬度
|
包裝
|
|
Item No.
|
L(鐵板孔徑)
|
Thread length
|
W. across flats
|
Packing
|
|
|
External threa
|
|
|
|
|
LWZHQ-M16
|
M16X1.5
|
31.5
|
21
|
50pcs
|
|
LWZHQ-M20
|
M20X1.5
|
31.5
|
25
|
50pcs
|
|
LWZHQ-M25
|
M25X1.5
|
31.5
|
30
|
50pcs
|
|
LWZHQ-M32
|
M32X1.5
|
31.5
|
37
|
50pcs
|
|
LWZHQ-M40
|
M40X1.5
|
31.5
|
45
|
20pcs
|
|
LWZHQ-M50
|
M50X1.5
|
35
|
55
|
20pcs
|
|
LWZHQ-M63
|
M63X1.5
|
35
|
68
|
20pcs
|
|
|
|
|
|
|
|
